JQ-BLP80-1 Brushless DC Water Pump
Rated Voltage: 12v-24v, Max Flow: 50L/min~58L/min, Max Head: 10m~12m, Power: 81W~120W
JUNQI 12V 24V Automobile Preheater Water Pump JQ-BLP80-1 12m Max Head ,Max Flow 58L/Min
Quick Techincal Data Description:
| Rated Voltage (V) | Voltage Range (V) | Max Head (m) | Max Flow (L/min) | Power (W) | Max Noise (dB) |
| 13.5V | 8-20V | 10m | 50L/min | 81W | ≤48dB |
| 24V | 12-30V | 10m | 50L/min | 88W | ≤48dB |
| 24V | 12-30V | 12m | 58L/min | 120W | ≤50dB |
Application:
1. Trucks motor control cooling cycle.
2. Automotive engine cooling circulation
3. The new enery automotive cooling cycle
4. Car's warm wind air conditioning cycle.
Technical Parameters Table:
| Model | JP-BLP80-1 |
| Rated Voltage | 13.5v,24v,24v |
| Voltage Range | 8-20V, 12-30V,12-30V |
| Max Flow | 50L/min, 50L/min, 58L/min |
| Max Head | 10m,10m,12m |
| Max Noise | ≤48dB,≤48dB,≤50dB |
| Power Consumption | 81W,88W,120W |
| Motor Type | Brushless DC Motor |
| Liquid Temperature | -40~120℃ |
| Ambient Temperature | -40~125℃ |
| Medium | water, Antifreeze |
| Pump Theory | Centrifugal Pump |
| Structure | Single-stage |
| OD of inlet | Ø22.3mm |
| OD of outlet | Ø22.3mm |
| Life time | 20000 H |
| Application | Vehicle |
| Protection Level | IP67 |
| Power supply | Battery/Electric/ Solar Panel |
| Material | PPS |
| Customized Functions | 1. Dry-running protection 2. PWM speed Control 3. FG Signal Output 4. Locked-rotor protection |
| Remarks | Not self-priming |
2. Mechanical installation
2.1 The pump can be installed vertically or horizontally mounted (see figure 1 ) When installed
vertically, the outlet port should be upward .
2.2 In order to avoid the dry- running (air get stuck in impeller),the water pump outlet port should
be vertical or in the upper of the impeller. (see figure 1 )
2.3 The connected pipe should be vertically mounted (or no elbow in 20cm )to make the air
discharged easily, the outlet pipe should not be used less than 90 degrees elbow (see figure 2).
2.4 Can't use the seawater or other heavy pollution with big grain impurity liquid as the liquid
medium .
